LED floodlight glass is the protective and often transparent or translucent covering used in LED floodlights. These lights are designed for outdoor and wide-area lighting, such as illuminating large spaces like stadiums, parking lots, or building facades. The glass in the floodlight plays several key roles:
Protection: It shields the LED bulbs or diodes from external elements such as dust, moisture, debris, and physical impact, ensuring the longevity of the floodlight.
Light Distribution: Depending on the type of glass, it can help diffuse or focus the light. Some floodlights use frosted or textured glass to soften the intensity of the light, while others use clear glass for maximum brightness and direct illumination.
Durability: The glass used in LED floodlights is usually toughened or tempered to resist breakage, especially since floodlights are often installed in outdoor or high-traffic areas.
Efficiency: By maintaining clarity and minimizing glare, the glass ensures that the light output is as efficient and effective as possible.
High Quality LED
50,000 Lifespan
Energy Saving
High CRI
| Product Code | Series | Watt | Weight(kg) | Surge | Dimension | ||
|---|---|---|---|---|---|---|---|
| Length (mm) | Breadth (mm) | Height(mm) | |||||
| SLFL 2030 (BC) | ECO Series | 30 | 0.475 | 4KV / 440V | 115 | 145 | 38 |
| SLFL 3050 (BC) | ECO Series | 50 | 0.980 | 6KV / 440V | 180 | 185 | 43.5 |
| SLFL 50100 (BC) | ECO Series | 100 | 1.520 | 6KV / 440V | 220 | 225 | 50 |
| SLFL 30 (BC) | FHW Series | 30 | 0.900 | 4KV / 440V | 180 | 185 | 43.5 |
| SLFL 50 (BC) | FHW Series | 50 | 1.450 | 6KV / 440V | 220 | 225 | 50 |
| SLFL 100 (BC) | FHW Series | 100 | 2.400 | 6KV / 440V | 275 | 285 | 55 |
| SLFL 150 (BC) | FHW Series | 150 | 2.550 | 6KV / 440V | 280 | 270 | 68 |
| SLFL 200 (BC) | FHW Series | 200 | 3.500 | 6KV / 440V | 335 | 365 | 70 |
| SLFL 300 (BC) | FHW Series | 300 | 5.700 | 6KV / 440V | 320 | 420 | 100 |
| SLFL 400 (BC) | FHW Series | 400 | 8.100 | 6KV / 440V | 350 | 525 | 100 |
| SLFL 500 (BC) | FHW Series | 500 | 9.500 | 6KV / 440V | 355 | 630 | 100 |
| Operating Voltage: 100 - 440VAC | IP Rating: IP 66 | Power Factor: >0.95 | CRI: >80 | Colour Temp: 3000K/4000K/6500K | |||
Parks
Hospital
Showrooms
Retail
Stadium
The floodlight glass in LED floodlights serves various applications across different industries and environments due to its protective, durable, and efficient design. Here are the key applications:
Sports Stadiums & Arenas : Used to provide powerful, focused illumination for large areas, allowing for night-time games and events. The glass helps distribute the light effectively across the entire field.
Parking Lots : Ensures bright, wide-area coverage for safety and security. The glass protects the floodlight from external damage and weather conditions.
Warehouses & Industrial Areas : Provides strong, reliable illumination for operational and safety purposes, ensuring workers have a well-lit environment even during the night or in dimly lit conditions.
Roadways & Highways : Ensures safe driving conditions by illuminating roads and highways, especially in low-light areas. The glass contributes to a focused and bright light output.
Construction Sites : Durable floodlight glass protects the lights used on construction sites, offering continuous, robust lighting even in harsh outdoor environments.
Outdoor Events : Used in temporary setups for concerts, fairs, or gatherings, providing even, bright lighting to large outdoor spaces, while the toughened glass ensures the lights can withstand physical impact and weather challenges.
